SMH General purpose power relay |

SMH General purpose power relay

Short Description:

Relay is an automatic switch element with isolation function, which is widely used in remote control, telemetry, communication, automatic control, mechatronics and power electronic equipment.

Price Term: FOB China port

Payment Term: TT, LC,PAYPAL,WESTERN UNION

OEM ORDER: Acceptance

General purpose power relay: Power Relay

Automotive Relays: Reed Relay

model: SMH

Send email to us Download as PDF

Product Detail

Product Tags

model	SMH
Overall dimension (mm)	22.7×12.3×27.4
Contact form:	1a
contact rating	16A 250VAC;16A 30VDC;TV-8 120VAC
Coil power (W)	0.5W
Coil voltage (VDC)	5~48VDC
Contact resistance	≤100mΩ
ambient temperature	-40℃~+85℃
Installation form	Printed board, socket type, quick connection type, flange type
