SRB General purpose power relay |

SRB General purpose power relay

Short Description:

Relay is an automatic switch element with isolation function, which is widely used in remote control, telemetry, communication, automatic control, mechatronics and power electronic equipment.

Price Term: FOB China port

Payment Term: TT, LC,PAYPAL,WESTERN UNION

OEM ORDER: Acceptance

General purpose power relay: Power Relay

Automotive Relays: Reed Relay

model: SRB

Brand: SANYOU

Send email to us Download as PDF

Product Detail

Product Tags

model	SRB
Overall dimension (mm)	20.5×7.0×15.1
Contact form:	1a
contact rating	5A 277VAC;3A 277VAC;3A 30VDC;1/8HP 240VAC;TV-3 120VA
Coil power (W)	0.2W,0.36W
Coil voltage (VDC)	5~24VDC
Contact resistance	≤100mΩ
ambient temperature	-40℃~+85℃
Installation form	Printed board, socket type, quick connection type, flange type
