SARJ-H Hot selling automobile relay
SARJ-H Hot selling automobile relay is an automatic switch element with isolation function, which is widely used in remote control, telemetry, communication, automatic control, mechatronics and power electronic equipment.
| Item Name | Automobile relay |
| model | SARJ-H |
| Overall dimension (mm) | 43×32.6×37.3 |
| Contact form: | 1a |
| contact rating |
30A（@450V）;80A(@80V)
|
| Coil power (W) | 1.6W |
| Coil voltage (VDC) | 12VDC,24VDC |
| Contact resistance | ≤200mV/at 10A |
| ambient temperature | -40℃ ~ + 85℃ (non condensing) |
| Installation form | Printed board, socket type |
