CD 60 Motor Start Capacitor

Short Description:

The CD60 series aluminum electrolytic capacitors are specially designed for starting motors in refrigerators, air conditioner compressors, water pumps, and other similar applications.

Item Name: CD60 Start Capacitor

MOQ: 100 PCS

Origin: Made In China

Send email to us Download as PDF

Product Detail

Product Tags

The CD60 series aluminum electrolytic capacitors are specially designed for starting motors in refrigerators, air conditioner compressors, water pumps, and other similar applications.

Specification:

Rated Voltage (VAC)	Nominal Capacity (μ F)	Dimension- DxL(mm)
220-275	40-70	37×70
	80-110	37×70
	108-140	37×70
	138-174	37×70
	161-193	46×86
	180-225	46×86
	225-270	46×86
	270-324	46×86
	324-380	46×111
	340-403	46×111
	400-500	46×111
	500-645	46×111
	645-708	52×111
	708-850	65×111
